The Classic is a professional grade mobile signal repeater that amplifies the GSM/4G/5G mobile signal, ensuring clear voice calls and super fast data speeds throughout the home.
It provides coverage for up to 5 rooms in a house.
The Classic Repeater amplifies the signal from all mobile operators, which allows everyone in the home to benefit from the improved signal.
How it works
The antenna on the roof receives the mobile signal from all mobile operators and transfers it through the cable to the Classic repeater.
The repeater amplifies the signal and spreads it around the building via the indoor antenna.
All mobile devices can now communicate with this enhanced signal.
Port Sense
Patent Pending Application No. 23179574.1
The Classic family of repeaters have a new patented feature called “Port Sense”. The repeater can detect when an antenna is connected to the indoor and outdoor antenna port. The new Smart antennas have a white LED embedded inside them. There is also a white LED on the ports of the repeater. These two white LEDs illuminate when the cables and antennas are correctly attached, giving the installer peace of mind. If the LEDs do not light up, there is likely an issue with the cables and/or connectors and therefore should be checked.
Advanced AGC control
The AGC (Automatic Gain Control) dynamic range of the repeater is now 35dB. For the installer, this means there is no need to add manual attenuation anymore, even in strong signal areas. AGC is now controlled automatically.
Advanced Feedback detection
Our new algorithm can accurately detect when a real oscillation event occurs. This can typically occur when the indoor and outdoor antennas are too close to each other. The red LED will turn on permanently to warn the installer to take action. The indoor and outdoor antenna should be separated by a solid wall.
A Closer Look
The R4-LCD
The R4-LCD has a touch LCD display instead of LEDs as an interface. This is useful if one needs to turn off a particular band. Sometimes this can enhance the performance of the repeater as it forces the cellular traffic to another, potentially faster band. Learn more about R4-LCD here.
The TestTool
The TestTool is a signal analyser specifically designed for mobile repeater installations. It helps installers to achieve optimized results for their installations. Read more here.
Shows the location, signal strength and power of each of the operator’s masts around the building.
Beacon Mode – Analyses how the signal propagates inside the building before the installation.
Ensures installation is done correctly and avoids costly errors.
Tests all cables.
Commissions projects – indoor coverage surveys before and after installation, which can be recorded for the client.
StellaPlanner
The StellaPlanner is our free online installation design tool which is accessible from the StellaControl platform. Installers can upload their building floor plans, place antennas, repeaters, splitters and cable in the correct location, and fully design the repeater system online before installing any equipment. This helps the installer to more accurately plan the equipment required and therefore potentially reduce the cost of the project.
The Stella Planner is supported by our Stella engineers, who offer expert design advice and support.
